TILTON 72-603 SERIES 600 FLOOR PEDAL BOARD

Tilton's 600 Series 3-Pedal Floor Mount Assembly features traditional fixed mount master cylinder and balance bar technology and provides excellent performance at competitive prices. Pedal assemblies are available in floor mount, firewall mount, and cantilever configurations.

characteristics :

• Forged aluminum pedals with adjustable pads (vertical and horizontal) and non-slip surfaces.
• Adjustable pedal ratio (5.29:1, 5.44:1, 5.61:1, 5.75:1) allows the brake pedal to be tuned to the rider's preference without having to change the master cylinder diameter.
• Large diameter 7/16”-20 balance bar provides maximum rigidity. PTFE coated aluminum forks for increased durability and reduced friction.
• The pedal pivots feature wave washers to reduce lateral pedal movement and oil-impregnated bronze bushings reduce sticking.
• The lightweight aluminum frame features guide “ramps” to reduce balance bar tip-over, decrease friction, and improve brake repeatability.
• Adjustable clutch pedal stop prevents clutch overload.
